FRANKS 1287 Drilling Rig For Sale
Asking Price $495,000
Email for more infoPriced to Sell NOW $495,000
7500' Capacity
Located in Oklahoma
NOW ACCEPTING OFFERS
Call to Inspect and Buy Today!!!
Call NOW! (800) 952-1973
Listing Details
Draw Works: 1287 Franks DW, 22” Parmac hydromatic. Powered by 60 Series Detroit, 5860 Allison Transmission
Derrick: Franks scoping 300,000 lb. 108 ft
Sub-base: 10’ x 12’ x 35’ T-Type
Mud Pumps: 1 – National 9P100 Mud pump powered by Cat 1000 HP D398 Motors
1 – National 8P100 Mud pump powered by CAT 3508
Top Dog House: 8’ x 25’ with 400 BBL water tank
Bottom Dog House/Generator House:
Rotary Table: Oilwell 17.5’
Swivel: Gardner Denver 125 ton
Kelly: 4.25’ x 42’ with Varco drive bushing
Mud Pit: 600 BBLS w/ premix compartment,
Mud Mixing Pumps: 2- Centrifugal 5’ x 6’ mission electric powered
Shell Shaker: Derrick Linear Motion
Desander: 2 cone
Electric Pit Agitators: 3 – 5HP
B.O.P.: 10 inch annular 3000 psi 9” 3000 Pipe & Bling Rams
Closing Unit: Three Station
Generators: 2 - 300 KW, Powered by Cat 3306
Catwalk: 5’ x 45’
Pipe Racks: 2 sets
Drill Pipe: 4 ½ X Hole, White Band
Drill Collars: 14, 6” – 6 ¼” Collars
Automatic Driller: Satellite
Drilling Recorder: Single pin Drillograph
Weight Indicator: Martin Decker
Standby Air Compressor: Ingersoll-Rand
Fuel Tank: 4000 Gallon Tank (skidded)
Survey Machine: Hydraulic powered, A-1 Sureshot, 14 Deg.
